Printing industry ink rub abrasion tester

FOB Reference Price:Get Latest Price
US $100-1,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Drick
Model Number:
DRK128
Power:
Electronic
Usage:
RUB TESTER
Rubbing pressure:
20±0.2N
Specimen Size:
230(L)mm*50(B)mm
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
plyood pacaging
Port
qingdao
Lead Time :
two weeks after confirmed





DRK128 printing industry ink rub abrasion tester

DRK 128 Rub Tester is applying in testing the abrasion of print ink, PS photosensitive coating and other relative products’ coating. It is used to analyze the printing abrasion, ink peeling and other products’ coating hardness. The equipment is designed according to GB7706, JIS K5701, and ISO 9000.



Product features

  1. The equipment is designed according to related standards strictly to ensure accurate test results.
  2. Memory when power failure ;
  3. Built-in standard rubbing platform to ensure a uniform rubbing area. And the rubbing process is mute completely.
  4. The rubbing time is adjustable in order to test accurately.
  5. Oscillation frequency automatic counting.



Product Application

The tester is applying in testing the abrasion of print ink. It is used to analyze the printing abrasion, ink peeling and other products’ coating hardness. It can be used to do dry grinding tests, wet grinding tests, decolorizing test, the paper fuzzy test and special rubbing test.



Technical standard

The tester accords with the standards of GB/T7706,ASTMD5264 TAPPI,JISK5701 etc.



Product parameter

  1. Rubbing pressure: 20±0.2N
  2. Rubbing speed: 43 times/min
  3. Rubbing area: 155(L)mm×50(B)mm
  4. Rubbing Times: 0~ 999 times.
  5. Specimen Size: 230(L)mm×50(B)mm
  6. Power: 220V; 50HZ
  7. Dimension: 260×245×340 mm (L × W × H)
  8. Net Weight: 17kg



Main fixtures

Mainframe, operating manual
