Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: DRICK
  • Model Number: DRK123
  • Power: Electronic
  • Usage: Compression Testing Machine
  • Test range: 1KN 5KN 10 KN(optional)
  • accuracy: 0.5grade 1 grade(optional)
  • Resolution: 0.1N 1 N
  • Deformation resolution: 0.001 mm
  • Pressing Plate: Parallelism between upper and lower pressing plate: ≤1mm
  • Test speed: 1-300 mm/min(infinitely variable speeds)
  • Return speed: 1--300mm/min(infinitely variable speeds)
  • stroke: 500mm
  • power: AC 220V 50 Hz

Packaging & Delivery

Packaging Details plywood packing
Delivery Time two weeks after order confirmed

Product Introduction



Box Carton Compression Tester  Box Compression Meter  is professionally used to test the compression resistance property of carton box, corrugated box, honeycomb cardboard box and other packaging. And it’s also applicable to container compression test of  plastic bucket (edible oil, mineral water), fiber drum, carton, paper, cans, container barrels (IBC barrels).





Product features



1. Computer control; eight-inch color touch-screen control panel, high-speed ARM processor to ensure high automaticity, fast data collection, test automatically and intelligent judgment

2. Three test methods:compression test; stacking test; press standard test;

3. Screen dynamic displays sample No., sample deformation, real-time pressure and initial pressure;

4. Open structure, double screw, double column, reduction gears drive reduction, good parallelism, good stability, strong rigidity, long service life;

5. Serve motor controls with high precise, low noise and high speed advantages; Accurate position and fast response speed save test time;

6. 24 high-precision AD converter (resolution up to 1 / 10,000,000) and high precision weighing sensor to ensure the speed and accuracy of the data acquisition of the instrument force;

7. Ultimate travel protection, overload protection, bugs prompt and fault prompts intelligent configuration to ensure safe operation; Micro-printer can print test data easily.

8. Connecting with computer can display curve, analyze test data, save and print data.





Product Application



It is applicable to do compression test, stacking test and press standard test of corrugated carton, cellular board case and so on.

Compressive strength test is applicable to test crushing force of all kinds of corrugated carton, honeycomb plate box and other packaging;

Stacking strength test is applicable to stacking test of all kinds of corrugated carton, honeycomb plate box and other packaging;

Pressure standards compliance test is applicable to pressure standard compliance test of corrugated carton, honeycomb plate box and other packaging;

It is also used to test pressure resistance property of plastic barrels, bottled mineral water bottles, bottled container anti-stress tests
